Aperçu ProduitsGénérateur CA Diesel

100kw marin triphasé générateur CA diesel de 3 sec

100kw marin triphasé générateur CA diesel de 3 sec

  • 100kw marin triphasé générateur CA diesel de 3 sec
  • 100kw marin triphasé générateur CA diesel de 3 sec
100kw marin triphasé générateur CA diesel de 3 sec
Détails sur le produit:
Lieu d'origine: Wuxi, Chine
Nom de marque: Werna
Certification: CE,ISO9001,SASO
Conditions de paiement et expédition:
Quantité de commande min: 5pcs
Prix: negotiation
Détails d'emballage: contreplaqué
Délai de livraison: d'ici 10 jours
Conditions de paiement: T/T
Capacité d'approvisionnement: 1000Units/Month
Contact
Description de produit détaillée
Courant évalué: 180A, 180A fréquence: 50Hz
Vitesse: 1500rpm ou 1800rpm Nom de produit: Générateur CA diesel
fabricant: Ville de Wuxi, Jiangsu Prov, Chine faisant des alternateurs Couleur: Facultatif
Surligner:

100kw Diesel AC Generator

,

3 sec Diesel AC Generator

,

100kw Diesel Marine Generator





ISO9001 50HZ 380V New Diesel Engine AC Three Phase 100kw Diesel Generator ​





Product Description



Technical parameters of diesel generator sets:
Technical data

Genset Model
land generators/marine generators
Prime Power
15kw-1000kw
Rated Voltage
400/230V
Frequency
50/60Hz
Power Factor
0.8(lagging)
The regulating rate of steady voltage
≤±0.5%
The regulating rate of instantaneous voltage
≤-15%/ +20%
The time of steady voltage
≤1.5sec
The waving rate of voltage
≤1.0%
The regulating rate of steady frequency
≤3%
The regulating rate of instantaneous frequency
≤±10%
The time of steady frequency
3 sec
Dimension (L×W×H) (mm)
2470*930*1440
Genset weight (kg)
1650
Diesel Engine

Brand
Weichai Yuchai SDEC Ricardo WANDE
Model
yuchai shangchai deutz perkins cummins and so on
Number of Cylinders
4,6,8,12
Rotating Speed
1500/1800RPM
Cycle
Four stroke
Type
waste gas turbine boost,direct spurting type
Speed Governor
Electrical /Mechanical
Cooling System
Water-cooled
Speed Stability (%)
≤5%
Fuel Consumption at 100% Load
200g/kw.h
Starting Method
DC24V Electrical starting
Alternator

Brand
Stamford /marathon /Xingnuo and so on type
Number of Phase
3
Connecting Type
Three Phase and Four Lines
Number of Bearing
1
Grading Protection
IP22
Altitude
≤1000m
Exciter Type
Brushless (AVR automatic voltage regulating)
Insulation Class
H degree
The components of the genset

(1) Cummins Diesel Engine; (2)Shanghai Stamford Alternator; (3) Control Panel
The control panel is Quadruplication protection control panel, with the display of frequency table/water temperature/schedule/battery voltmeter. The genset with low oil pressure, high water temperature, over speed emergency, stop and other pre-protection.





Quick Detail:





Name

ALTERATOR

Brand Name

WERNA

Color

According to the international standard color card

Feature

AC brushless synchronous excitation alternator


Power

          20kw

Certificate

CE,ISO9001,SASO






Specifications:





Model

WR182H

manufacturer

 Wuxi City ,Jiangsu Prov ,China making alternators

Output Type

AC Single Phase diesel generator

Terminal

12 / 6 Wire

Rated Voltage

110-240V

Frequency

50HZ

Speed

1500RPM

Mounting dimensions

Stamford Type

Winding Pitch

2 / 3 pitch

Excitation

Brushless, self-excited, synchronous

Insulation Class

H




Description:


Frequency And Voltage
50Hz or 60Hz as per customer’s request. Voltage from 380 ~ 690V, 190V~345V, 220~400V, serial star, parralle star and serial delta connection are available, All three-phase generators are 12-lead reconnectable, providing voltage and phase flexibility.
Insulation and Protection
Insulation: H, Protection: IP22
Voltage Regulators
The model we use including: MX321, MX341, AS440, SX440, SX460, etc.
Winding
All generator stators are wound to 2/3 pitch.
The quality management system of our factory
A set of integrated quality management system,there are standard imported checking rules of every component.All the suppliers should be selected and checked strictly by our factory,all the materials should be appointed specially after the strict selection by our factory.
Competitive Advantage:
1. 100% copper winding wire
2. In stock and fast delivery
3. Two year warranty
4. Best quality and competitive price
5. Two-time vacuum impregnation dipping
6. powerful quality control team
6. CE,ISO9001
7. Good after-sale service
